Dash Workshop: Part 2

Eric Manley, Drake University

What are we covering

In Part 1, we covered

• Getting everything installed
• Building web apps with user interface components like input boxes, radio buttons, and dropdown menus
• Callbacks, with several variations
• Loading data into our apps from a file

In this part, we'll

• Show how to use Dash with Plotly data visualizations

Reference: https://dash.plotly.com/

What is Plotly?

• graphing library
• open source
• interactive graphs
• often works with your data in just one line of code

Screen shot from https://plotly.com/python/

Installing Plotly

In Codespaces, it seems we probably don't need to install anything, but if you're working in another environment...

python3 -m pip install pandas
python3 -m pip install plotly

A Plotly example using our csv movie data

import plotly.express as px
import csv

# reads data from a file into a 2d list
def data_prep(filename):
    with open(filename) as movie_file:
        data_reader = csv.reader(movie_file)
        data = []
        for row in data_reader:
            data.append(row)
        return data


# convert strings to ints along one column in the 2D list
def convert_column_to_int(data_2d_list,col_num):
    for row in data_2d_list:
        row[col_num] = int(row[col_num])


data = data_prep("HighestHolywoodGrossingMovies.csv")
header = data[0]
data = data[1:]
convert_column_to_int(data,7) #world sales is read in as a string by default

# 1 - the column index for movie titles
# 7 - the column index for world sales numbers
fig = px.bar(data,x=1,y=7,labels={"1":"Title","7":"World Sales ($)"},title="Movie Sales")
fig.show()

What about other data formats?

Again, most Plotly examples use Pandas dataframes, but you don't have to teach your students Pandas

It works even better with a list of dictionary records (e.g., common with JSON)

Here's a way you can convert CSV data to JSON for your students

• I suggest doing this part for the students and just giving them the JSON file

import pandas as pd

df = pd.read_csv("HighestHolywoodGrossingMovies.csv")
df.to_json("HighestHolywoodGrossingMovies.json",orient="records")

Here's the file: HighestHolywoodGrossingMovies.json

Here's what that data looks like

import json
from pprint import pprint

with open("HighestHolywoodGrossingMovies.json") as json_file:
    data = json.load(json_file)
    pprint(data[:3])

[{'Distributor': 'Walt Disney Studios Motion Pictures',
  'Domestic Sales (in $)': 936662225,
  'Genre': "['Action', 'Adventure', 'Sci-Fi']",
  'International Sales (in $)': 1132859475,
  'License': 'PG-13',
  'Movie Info': 'As a new threat to the galaxy rises, Rey, a desert scavenger, '
                'and Finn, an ex-stormtrooper, must join Han Solo and '
                'Chewbacca to search for the one hope of restoring peace.',
  'Movie Runtime': '2 hr 18 min',
  'Release Date': 'December 16, 2015',
  'Title': 'Star Wars: Episode VII - The Force Awakens (2015)',
  'Unnamed: 0': 0,
  'World Sales (in $)': 2069521700},
 {'Distributor': 'Walt Disney Studios Motion Pictures',
  'Domestic Sales (in $)': 858373000,
  'Genre': "['Action', 'Adventure', 'Drama', 'Sci-Fi']",
  'International Sales (in $)': 1939128328,
  'License': 'PG-13',
  'Movie Info': 'After the devastating events of Avengers: Infinity War, the '
                'universe is in ruins. With the help of remaining allies, the '
                "Avengers assemble once more in order to reverse Thanos' "
                'actions and restore balance to the universe.',
  'Movie Runtime': '3 hr 1 min',
  'Release Date': 'April 24, 2019',
  'Title': 'Avengers: Endgame (2019)',
  'Unnamed: 0': 1,
  'World Sales (in $)': 2797501328},
 {'Distributor': 'Twentieth Century Fox',
  'Domestic Sales (in $)': 760507625,
  'Genre': "['Action', 'Adventure', 'Fantasy', 'Sci-Fi']",
  'International Sales (in $)': 2086738578,
  'License': 'PG-13',
  'Movie Info': 'A paraplegic Marine dispatched to the moon Pandora on a '
                'unique mission becomes torn between following his orders and '
                'protecting the world he feels is his home.',
  'Movie Runtime': '2 hr 42 min',
  'Release Date': 'December 16, 2009',
  'Title': 'Avatar (2009)',
  'Unnamed: 0': 2,
  'World Sales (in $)': 2847246203}]

And here's what the Plotly code looks like

import plotly.express as px
import json

data = []
with open("HighestHolywoodGrossingMovies.json") as json_file:
    data = json.load(json_file)

fig = px.bar(data,x="Title",y='World Sales (in $)',title="Movie Sales")
fig.show()

Exercise 1

This visualization has too many things on the x axis!

Can you write some code so that it only plots a subset of the data?

• Only movies with "Star Wars" in the title
• Only movies from a particular year
• Only comedies

Make it your own

Dash + Plotly

One of the really cool things about Dash is that it is designed to work well with Plotly.

There is a Dash component called Graph which expects a parameter called figure - you can pass that any kind of Plotly figure.

from dash import Dash, html, dcc
import plotly.express as px
import json


data = []
with open("HighestHolywoodGrossingMovies.json") as json_file:
    data = json.load(json_file)

app = Dash(__name__)

app.layout = html.Div(children = [
    dcc.Markdown(
        id = "title",
        children = "## Movie Sales Dashboard"
    ),

    dcc.Graph(
        id = "movie_sales_bar_graph",
        figure = px.bar(data,x="Title",y='World Sales (in $)',title="Movie Sales")
    )
])

if __name__ == '__main__':
    app.run_server(debug=True)

Changing the figure with a callback

The figure parameter of a dcc.Graph can be updated by a callback function

from dash import Dash, html, dcc
from dash.dependencies import Input, Output
import plotly.express as px
import json


def get_movie_titles(data_records):
    titles = []
    for item in data_records:
        titles.append(item["Title"])
    return titles

data = []
with open("HighestHolywoodGrossingMovies.json") as json_file:
    data = json.load(json_file)

app = Dash(__name__)

app.layout = html.Div(children = [
    dcc.Markdown(
        id = "title",
        children = "## Movie Sales Dashboard"
    ),

    dcc.Dropdown(
        id = "titles_dropdown",
        options = get_movie_titles(data),
        value = ["Star Wars: Episode VII - The Force Awakens (2015)","Avengers: Endgame (2019)"],
        multi = True
    ),

    dcc.Graph(
        id = "movie_sales_bar_graph",
        figure = px.bar(data,x="Title",y='World Sales (in $)',title="Movie Sales")
    )
])


@app.callback(
    Output("movie_sales_bar_graph","figure"),
    Input("titles_dropdown","value")
)
def update_sales_graph(selected_title_list):
    records_to_display = []
    for movie_record in data:
        if movie_record["Title"] in selected_title_list:
            records_to_display.append(movie_record)
    new_fig = px.bar(records_to_display,x="Title",y='World Sales (in $)',title="Movie Sales")
    return new_fig

if __name__ == '__main__':
    app.run_server(debug=True)

Exercise 2

Here's some data from the WHO on life expectancy

HALElifeExpectancyAtBirth.csv

HALElifeExpectancyAtBirth.json

source: https://www.kaggle.com/datasets/utkarshxy/who-worldhealth-statistics-2020-complete

Create a dashboad with this data.

See Plotly chart examples here: https://plotly.com/python/

Plotly Maps

See map examples at https://plotly.com/python/maps/

import plotly.express as px
import json


def filter_data(data_records,year,sex):
    relevant_records = []
    for item in data_records:
        if item["Period"] == year and item["Dim1"] == sex:
            relevant_records.append(item)
    return relevant_records

data = []
with open("HALElifeExpectancyAtBirth.json") as json_file:
    data = json.load(json_file)


display_data = filter_data(data,2019,"Both sexes")

fig = px.choropleth(display_data,locations="Location",locationmode="country names",color="First Tooltip",labels={'First Tooltip':'Life Expectancy (years)'},title="Healthy Life Expectancy at birth, 2019")
fig.show()

How do I host my apps on the web?

Dash provides easy-to-follow instructions for deploying on Heroku: https://dash.plotly.com/deployment

• free until recently 🙁
• $5/month low-use plan

You may be able to do it for free on PythonAnywhere: https://towardsdatascience.com/the-easiest-way-to-deploy-your-dash-app-for-free-f92c575bb69e

One of my students (Jae Choi) put together a template for deploying a Dash app on AWS Lambda (some free requests, $0.20 per million requests): https://github.com/Jaethem8y/dash-serverless-template
